Sus304 Plastic Bottle Washer Single Station 300BPH

Minimum Order Quantity : 1 Price : by Negotiate
Packaging Details : Wooden Case Package Delivery Time : 15-20days after deposit receipt
Payment Terms : L/C, D/A, D/P, T/T, Western Union Supply Ability : 30 set / month
Place of Origin: China,JiangSu,Zhangjiagang Brand Name: FillPack
Certification: CE. ISO9001 Model Number: BS-1, S-1, BS-2, S-2

Detail Information

Station Qty: Singel Or Double Capacity: 100-300BPH
Material: SUS304 Function: Gallon Bottle Washer
Name: 5 Gallon Bottle De-capper Machine Condition: New
Packing: Wooden Packing Warranty: 1 YEAR
High Light:

Sus304 plastic bottle washer

,

300BPH plastic bottle washer

,

300BPH single station bottle washer

Product Description

Semi-auto de-capping machine and the de-capping heads SUS304



Worker put used jar in right side of de-capper position, with the neck inserting into the hole, worker foot press pedal to release cap off neck; And then worker need to take the jar to insert into left side of the machine-washing position. After the jar putting in, the window need to be closed. Then the washer will be started by itself. During washing, the inner brush inside jar and Washing time is pre-settled, the machine will stop when time finish. Heating function could be switched on/ off as client’s needing.


Parameters of this Gallon bottle washer:
Power 1.12kw without heating, 2.12kw with heating
Capacity 100-300 bottles per hour

Plate thickness

1mm

Machine cube size

25*25mm

Cube thickness

1.5cm



De-capping system Inside jar brushes and water jet pipe
Sus304 Plastic Bottle Washer Single Station 300BPH 0 Sus304 Plastic Bottle Washer Single Station 300BPH 1
Back electronics Schneider electronics
Sus304 Plastic Bottle Washer Single Station 300BPH 2 Sus304 Plastic Bottle Washer Single Station 300BPH 3



Connection way for reference:

Sus304 Plastic Bottle Washer Single Station 300BPH 4





Packing informations for each model of machines:

Model Description Packing Qty. Dimensions(mm) Weight
BS-1 de-capper and brush washer







Wooden case

1Package 900*900*1250 250KG
S-1 brush washer(single station) 1Package 600*750*1150 200KG
BS-2

de-capper and brush washer

(double station)

1Package 1300*750*1150 300KG
S-2 brush washer(double station) 1Package 1300*750*1150 300KG
BSC-1 de-capper and brush washer with inner rinser 1Package 1200*750*1150 280kg



Spare parts for free:

Inner brush*1



Q1. If I want to buy this machine, when can you ship it as soon as possible?

A1: Normally, our warehouse is in stock and we can ship it at any time after receiving the order.

Q2. Do you have other different models?
A2: Yes, we have different models with different heads quantity, which can be customized according to the customer's production requirements.

Q3. Do you have equipment related to this machine?
A3: The machines associated with this machine are: 5 gallon blow molding machine, RO small water treatment plant, 5 gallon water filling machine, and so on.
