Reverse Osmosis 4000L/H Industrial Water Treatment / Pure Drinking / Machine / System / Line

June 30, 2020

Latest company case about Reverse Osmosis 4000L/H Industrial Water Treatment / Pure Drinking / Machine / System / Line

Reverse Osmosis 4000L/H Industrial Water Treatment / Pure Drinking / Machine / System / Line


Product introduction:

According to the customer requirements and the source water quality, we adopt different equipment to produce pure water, mineral water, etc. The main equipments are silica sand filter, active carbon filter, sodium ion exchanger, hollow fiber, RO( reverse osmosis), UV sterilizer, precision filter, ozone generator, water tank, etc. The treatment capacity is 0.5-50 ton/hour. It can effectively get rid of muddy organic matter, iron, manganese and oxide, filter suspended substance, colloid, remained oxygen of microorganism and some of heavy metal ion in the water, reduce the hardness of the water to make all specifications of the water quality fully meet the state fresh water standard of fresh drink water.



Flow Chart:

Raw water tank—raw water pump—multi-medium filter--active carbon filter –water softner (Sodium Ion Exchanger)—precision filter—RO mainframe(including chemical cleaning device)—ozone generator—finished product water tank

Silica sand filter It can remove the suspended solids and gluten particles in the water, thus reduce turbidity of water.
Active carbon filter It can remove the pigment, smell and a large number of biological organisms in the water.
Sodium ion exchanger It can remove calcium and magnesium ions in the water, so as to sofen the water.
Precision filter It can ensure that granularity of the water into reverse osmosis membrane is less than 0.1um.
Reverse Osmosis The Reverse Osmosis Device is an equipment to purify the saline water with the action of pressure difference of semi-permeable membrane.It is called reverse osmosis, as it is counter to natural penetration direction. Different material have different osmosis pressures.The reverse osmosis can remove more than 97% of the soluble salt and above 99% of the colloid, microorganism, particles and organic materials, becoming the best first-choice equipment in the engineering of modern purified water, highly purified water and space water(super-purified water).The most highlighted features are low energy consumption, no pollution, simple technique, high-quality water and convenient operation and maintenance.
UV sterilizer It uses the UV to kill some bacteria that may also pass through the reverse osmosis system.
Ozone sterilizer Some bacteria may not be killed by the UV, the sterilizer uses ozone to kill those bacteria.


Consumables Replacement Cycle

NO. ITEM Replacement cycle
1. Pure water silica sand 2~3yeas
2. Pure water activated carbon 1~2yeas
3. Filter cartridge 2~3month
4. RO membrane 2~3yeas


Competitive Advantage:

1. Our machine is with good quality and price, we can make the machine customized for you if need.

2. Our company has been established more than 15 years, we are a professional manufacturer in every kind of beverage production machine.

3. We have the certifications of ISO, CE and so on.

4. Our company machines are exported to many countries abroad every year.

5. We can offer free technician support and consultation to help you to order a new equipment and start a new company.

6. We can offer one year guarantee for the machine you ordered freely, forever technology supports in our machine and related machine.

7. W can send our technician to your country for machine commissioning and instruction conveniently.

8. Your inquiry will be replied within 24 hours, you are welcome to contact me in your convenience, please feel free to contact me if any question you have.
