1000BPH Gallon Water Filling Plant For 20L Barrel Water Line

Minimum Order Quantity : 1 set/pcs Price : USD$38,000.00-USD$43,000.00
Packaging Details : Wooden case pacakge Delivery Time : 30-35days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 5 sets/month
Place of Origin: ZhangJiaGang JiangSu China Brand Name: FILL PACK
Certification: CE, ISO9001 Model Number: QGF-1000

Detail Information

Bottle Size: 3-5 Gallon Bottle Capacity: 1000BPH
Material: SUS 304 Automatic Grade: Automatic
Keyword: Bottled Water Making Machine Control: PLC+Touch Screen
Capping Type: Sealing Video Outgoing-inspection: Provided
High Light:

1000BPH gallon water filler

,

20L gallon water filler

,

1000BPH mineral water making machine

Product Description

3 / 5 gallon / 20L bottle water washing filling capping equipment / plant / machine / system / line



This gallon filler specially produces 3&5 gallons barreled drinking water. This series gallon filler integrates bottle washer, filler and sealer into one unit.

Items
Name of machine
Model
Size(mm)
Qty.
1200BPH gallon water filler
1
Automatic de-capper
BG-3
1200*800*1950
1set
2
Rotary external washer
XT-3
1800*1550*1750
1set
3
Monoblock jar rinser
CXJ-3
6000*2100*2100
1set
3.1
Automatic jar loading-unloading device
ST-6
/
1set
4
Automatic rotary jar filler
TG-12
3000*2200*2500
1set
4.1
Automatic belt capper
LDYG-1
600*200*300
1set
4.2
Automatic cap lifter-washer
SG-1
800*800*3000
1set
5
Steam shrink tunnel
SB-1000
1000*450*1500
1set
6
Light checker
DJ-1
800*200*300
1pc
7
Belt conveyor system
SYS-1
35m
1set
8
Ink jet code printer
PM-368
347*220*100
1set
OPTION




8
Automatic neck labeling machine
TB-50
1000*800*2000
1set
8.1
Steam shrink tunnel
SB-1000
1000*450*1500
1set
8.2
Steam generator
9KW
630*560*1360
1set
9
Automatic stacker
5*4*3
2700*2000*2000
1set



Details of main machines

1000BPH Gallon Water Filling Plant For 20L Barrel Water Line 0

Automatic de-capper


This machine is driven by cylinder, controlled by PLC; Automatic working by barrel checking;
De-capping head is composed by claw device and cylinder, de-capping head position can move up and down, claw device can be adjusted slightly to be suitable for different caps.

Automatic rotary jar filler



Bottle fed by a star wheel into the bottle filling machine, filling area to reach the starting point, the roller bottles along the cam will hold up, start filling valve for filling a bottle, and with the body, etc. together synchronously rotating; bottles arrive irrigation end point loading zone, to reach the cam roller bottles with low self-reset Close filling valve, filling the end of the barrel with the star wheel sent out of the bottle filling machine.

1000BPH Gallon Water Filling Plant For 20L Barrel Water Line 1
1000BPH Gallon Water Filling Plant For 20L Barrel Water Line 2

Automatic neck labeling machine



Adopting model group design, module controlled; Achieve veracity and fast sleeving.
With the good quality touching operation screen, achieving operation by finger, easy and shortcut.
It is a high automatic packing machine. Just one person handles, easy operation.
Higher safely and stability for operation and saving time of manpower.

Steam shrink Machine



Whole SUS304 construction, including electrical boiler to generate steam and shrink tunnel especially for barrel cap film;

Power: 20KW
Dimension: 1000*600*1200mm
Weight: 100kg

1000BPH Gallon Water Filling Plant For 20L Barrel Water Line 3
