1200bph 5 Gallon Mineral Water Bottling Machine For Water Production Line

Minimum Order Quantity : 1 set/pcs Price : USD$38,000.00-USD$43,000.00
Packaging Details : Wooden case pacakge Delivery Time : 30-35days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 5 sets/month
Place of Origin: ZhangJiaGang JiangSu China Brand Name: FILL PACK
Certification: CE, ISO9001 Model Number: QGF-1000

Detail Information

Bottle Size: 3/5 Gallon Bottle Capacity: 1000BPH
Material: SUS 304 Driven Type: Electric
Core Components: Motor, PLC, Bearing, Engine Warranty: 1 Year
Function: Bottle Washing Filling Capping Bottle Type: PET Plastic Bottle
High Light:

1200bph Mineral Water Bottling Machine

,

5 gallon Mineral Water Bottling Machine

,

1200bph mineral water filling machine

Product Description

1200bph 5 gallon bottles outside brusher machine for water production line

1200bph 5 Gallon Mineral Water Bottling Machine For Water Production Line 0

1.1, Automatic De-capper

This Gallon bottle outside brusher line is driven by cylinder, controlled by PLC; Automatic working by barrel checking;
De-capping head is composed by claw device and cylinder, de-capping head position can move up and down, claw device can be adjusted slightly to be suitable for different caps.
When the gallon bottle comes into the machine, the de-capping head will go down and claw device will hold tightly barrel cap sides, and then lift the barrel to take off the caps; And when the caps are taken off, the compressor air will blow the caps into cap hopper, then fall outside into client’s own holder;
The claw pressure is adjusted to protect caps;

1200bph 5 Gallon Mineral Water Bottling Machine For Water Production Line 1
Parameters
Cap pulling claw
3 pcs
Power
0.2KW
Dimension
1200*800*1950mm
Weight
200kg

1.2, Rotary external washer

1200bph 5 Gallon Mineral Water Bottling Machine For Water Production Line 2

General

The Gallon bottle outside brusher line is used for gallon jar outside brush washing; When the jars are sent into the machine by the conveyor, the brushes inside driven by motor will rotate quickly. The main brush shape is made according to jar shape and size which the jar neck and shoulder will be washed completely. Water showing will be done at the same time of brush washing.



Dimension: 1800*1550*1750mm
Weight: 200kg
Power: 3KW

1200bph 5 Gallon Mineral Water Bottling Machine For Water Production Line 3

1, Rack: entirely by 75x45 square tube welded stainless steel, high strength, good rigidity, light weight, beautiful appearance, easy to clean and so on. Automatic bottle bodies and chassis welding.
2, Conveyor: driven sprocket, chain, prop bottle rack, solid bottle cups, etc., in which chains, sprockets have been carefully designed to make it more scientific and more perfect.
3, Main driving: frequency control bottle bottle conveyor station every one stays fixed time, chain plate relative to the position of the automatic bottle and the angular position off the bottle also undergo a rigorous calculation to ensure accurate positioning of the entire automatic operation .
4, Adjusting: You can adjust the chain end bearing bolts to ensure that the whole chain of elastic consistency.
The pipes are made of stainless steel washing machine pipe connection, using my company unique rotating spiral nozzle, washing points stronger efforts to good effect, high efficiency no dead ends.
