5 Gallon Semi Auto Bottle Rinser Washer Manual Feed Single Station With Full SUS304

Minimum Order Quantity : 1 set Price : 750 USD
Delivery Time : 15 Working Days After Deposit Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability : 20 Sets Per Months
Place of Origin: Zhangjiagang, China Brand Name: FILLPACK
Certification: CE/ISO9001 Model Number: BS-1

Detail Information

Capacity: 150-280BPH Pulling Head: 1
Processing Types: 3-5 Gallon Bottle Material: SUS304
Core Components: PLC Dimension(L*W*H): 900*900*1250
Weight: 250 KG Automatic Grade: Semi-automatic
Packaging Type: Barrel Application: Beverage
High Light:

5 gallon bottle rinser washer

,

Single Station bottle rinser washer

,

Single Station pressure bottle washer

Product Description

3-5 Gallon Semi-Auto Brush Washer Manual Feed Single Station With Full SUS304

5 Gallon Semi Auto Bottle Rinser Washer Manual Feed Single Station With Full SUS304 0

Overview:

The washing machine is an indispensable equipment in the empty barrel pretreatment process of the drinking water production line, and it usually works with the air compressor. In order to adapt to the needs of most mineral water plants and pure water plants, the cumbersome empty barrel processing technology has become simple automation. Our company introduces and absorbs the advanced technology of brushing barrels at home and abroad, and combines the actual situation of existing manufacturers with the management regulations of drinking water industry to develop the BS-1 5 gallon barrel brushing machine. The device integrates the bottle cap and cleans the inside and outside of the barrel, and has reliable performance, simple operation and convenient maintenance.



Work process:

Worker put used jar in right side of de-capper position, with the neck inserting into the hole, worker foot press pedal to release cap off neck; And then worker need to take the jar to insert into left side of the machine-washing position. After the jar putting in, the window need to be closed. Then the washer will be started by itself. During washing, the inner brush inside jar and Washing time is pre-settled, the machine will stop when time finish. Heating function could be switched on/ off as client's needing.



Parameters:

Power
1.12KW without heating, 2.12KW with heating
Dimension
900*900*1250mm
Weight
250kg



Details:

5 Gallon Semi Auto Bottle Rinser Washer Manual Feed Single Station With Full SUS304 1

5 Gallon Semi Auto Bottle Rinser Washer Manual Feed Single Station With Full SUS304 2
