Ship Using Reverse Osmosis Water Treatment Machine / Seawater Desalination Machine

Minimum Order Quantity : 1 set Price : 2650USD
Packaging Details : Wooden case Delivery Time : 7-15days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 20 sets per month
Place of Origin: Zhangjiagang, China Brand Name: Fillpack
Certification: CE/ISO9001 Model Number: 1T/D、2T/D、3T/D

Detail Information
Production Capacity: 1000-3000L/Day Name: Seawater Desalination Machine
RO Membrane: SW11-4021/SW11-2540 Material: Wooden Case, SS304+FRP
High Pressure Pump: 1.5KW/130bar Function: Producing Fresh Water
Size: 1200*600*600mm Weight: 110KG
High Light:

Reverse Osmosis Water Treatment Machine Portable

,

1.5KW Seawater Desalination machine

,

3000L/Day Seawater Desalination machine

Product Description

1-3T/D Seawater Desalination Machine / System for Mini Portable / Ship Using Reverse Osmosis Water Treatment Machine



General:
The seawater desalination equipment applies the principle of reverse osmosis technology.
Composition:raw water pump,cartridge filter,RO Unit ,Electrical control system and Pipeline system,RO is the core of the system.
Raw water pump :
Provide necessary flow and pressure for equipment afterwards.
Cartridge filter:
TO avoid the impurity into RO membrane,It can filter the impurities of 5 microns in the water,Therefore, it plays a role in protecting the RO membrane.
RO Unit
The reverse osmosis system includes high -pressure pumps, reverse osmosis membrane,RO membrane shell,Washing water tank(1T is not included).The water in the cartridge filter is further treated into freshwater.
The basic process of reverse osmosis portable/ship using seawater desalination water treatment machine is:
Sea water is extracted from the raw pump into the cartridge filter.cartridge filter filtering out the impurities of 5 microns in the water.The filtered water enters the high -pressure pump. Under the action of high -pressure pumps, it flows through the high desalination membrane.Seawater forms fresh water under the filtering of the membrane.

Parameters

Name
Specification/
Model
Unit
Qty
Place of origin
Remark
1
Raw water pump
0.37kw
set
1
Guangdong
Ling Xiao
2
Filter housing
10″-1
piece
2
Domestic

3
Filter cartridge
10″—5μ
piece
1
Domestic
fiber
4
Filter cartridge
10″—3μ
piece
1
Domestic
fiber
5
Engine
Y100L-4
set
1
Domestic
1.5KW
6
High-pressure pump
P319(1.5KW)
set
1
import
130bar
7
Triangular belt
A-40″
piece
2
/
/
8
Belt wheel
D150
piece
1
/
/
9
Belt wheel
D140
piece
1
/
/
10
RO membrane
2T/D
SW11-4021
piece
1
/

Vontron
1T/D

SW11-2540
piece
1
/
3T/D
SW11-2540
3T/D
2
/
11
RO membrane shell
2T/D
F4021-1W
piece
1
Domestic
FRP
1T/D

F2540-1W
piece
1
3T/D
F2540-1W
piece
2
12
pressure regulating valve
DN15
piece
1
Domestic
SS safety valve
13
panel pressure gauge
10Mpa YX60
piece
1
Domestic
Shockproof
Accuracy:2.0
14
panel pressure gauge
0.6Mpa YX60
piece
1
Domestic
Shockproof
Accuracy:2.0
15
High -voltage electrical Contact Point pressure gauge
10Mpa
piece
1
Domestic
Shockproof
Contact with electric
16
Flow meter
1GPM
piece
1
Zhejiang
Panel form
17
Conductivity meter
CM320
piece
1
Domestic
Contains sensors
18
Pressure Switch
JY-2
piece
1
Domestic
Ship using
19
Frame of machine
/
piece
1
/
SUS304
20
Washing water tank
1T/D
/
/
/
/
/
2T/D
3T/D
20L
Piece
1
/
PVC
21
Electrical control system
/
suit
1
/
/
22
Pipeline system
DN20
suit
1
/
SS316 for HP connectors
PVC for other
23
Attach 30 pieces PP cotton filter cartridge
