Automatic SUS304 20L Bottle Cleaning Machine 600BPH Capacity

Minimum Order Quantity :	1 Set	Price :	Further Discussion
Packaging Details :	wooden case	Delivery Time :	15-25 working days
Payment Terms :	L/C,D/A,D/P,T/T,Western Union	Supply Ability :	1 set/month

Place of Origin:	ZhangJiaGang City,JiangSu Province,China	Brand Name:	FILL PACK
Model Number:	WSNCT-5

Detail Information
Applicable Bottle Size:	18.9L ,5 Gallon,20L	Applicable:	Gallon Water Factory
Materail:	SUS304	Washing Solution:	Alkalic Water
Function:	Inner HP Rinsing-outer Brush Washing	Rinsing Pressure:	0.6-1Mpa

Product Description

Automatic SUS304 20L Bottle Cleaning Machine 600BPH Capacity

The external brushing and internal high-pressure rinsing machine is designed for efficient pre-washing of 5-gallon and 20L water bottles. The machine integrates a rotating outer brush with high-pressure internal rinsing to remove dust, dirt, and residual impurities from both the barrel surface and inner wall.
Built with SUS304 stainless steel, the structure is durable, corrosion-resistant, and suitable for long-term operation in water
plants. The combined inner–outer cleaning process ensures cleaner bottles before entering the main washing or filling line,helping improve final product hygiene and reduce contamination risks.

Product Advantages:

1. High Output – 450BPH Stable Performance
Designed for continuous production with a reliable capacity of 450 bottles per hour, ideal for medium and large water plants.
2. Strong Inner Cleaning with 0.6–1MPa High-Pressure Rinsing
Powerful internal rinsing removes sediment, residues, and contaminants thoroughly before the main washing process.
3. Effective Outer Brush Washing for Better Appearance
Rotating outer brushes clean dust, stains, and surface dirt to ensure the bottle looks clean inside and out.

Model	WSNCT-5
Capacity	600BPH
Function	Inner HP rinsing-outer brush washing
Washing station	5
Rinsing pressure	0.6-1Mpa
Weight	850KG
Applicable bottle size	18.9L
power	17.5KW
Size230015502300mm	270016002350mm
Application	Gallon water factory
Gallon bottle size	D270*H490mm
Washing solution	Alkalic water

Automatic SUS304 20L Bottle Cleaning Machine 600BPH Capacity 0

FAQ

Q1: Do you provide customized service?
A1:Yes, we do. Whether it's for purified water, mineral water, carbonated drinks, juice, tea, or beer production lines, we can

customize the equipment based on your requirements — including material, functions, capacity, bottle type, and factory layout.

Q2: Do you offer OEM&ODM services?
A2: Yes. We can customize the LOGO and products according to your needs.
Q3: Where is your factory located? Can I visit you?
A3:Our factory is located in Zhangjiagang City, Jiangsu Province, China — very close to Shanghai.
