Manual Loading 200 BPH 20 Liter Jar Filling Machine

Minimum Order Quantity : 1 set/pcs Price : USD$4,850.00-USD$6,000.00
Packaging Details : Wooden case pacakge Delivery Time : 30-35days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 10 sets/month
Place of Origin: ZhangJiaGang City, JiangSu Province, China Brand Name: FILLPACK
Certification: CE,ISO Model Number: QGF-200

Detail Information

Voltage: 380V/50HZ Condition: New
Packaging Material: Plastic Packaging Type: Barrel
Bottle Type: 3gallon-5gallon Pump: NANFANG
Product Name: 3-5 Gallon Water Filling Machine Capacity: 200 BPH
High Light:

20 ltr water jar sealing machine


20L Gallon Filling Machine


10L Gallon Filling Machine

Product Description

10 - 20L Gallon Bottling Plant / Machine / Unit With Manual Loading


Working process of Gallon Bottling Plant:

Barrel filling unit can be divided into 3 steps: washing, filling and capping, total 9 working stations,working process as below:

(1) Set empty barrel mouth to barrel seat, empty barrel will be washed during headstand situation,4 working station for barrel inserting.

(2) Washing process will be divided into 4 steps:1, hot alkali water washing 2,thimerosal washing;3,clean water washing,4,pure water washing.Every washing step is set to 8S,after washing,there will be 10S for dripping.

(3) The barrel after washing will move down 45 degree through the passing chain and will passing out chain and turn over 45 degree by barrel lift cylinder to filling position for filling.

(4) Filling value will driven by cylinder to insert into barrel and start to fill, filling time is controlled by PLC, and filling time is adjustable by control panel according to filling liquid surface.After filling, the extra water will back to pure water tank by automatic vent,it can reduce water consumption.(water tank is not included)

(5) After filling process finish,the filled barrel will be pushed to capping position by barrel stop cylinder,the whole process finish till now.


Features of Gallon Bottling machine:

1. This filling machine specially produces 5 gallons barreled drinking water.
2. This series barreled filling production machine integrates bottle washer, filler and sealer into one unit.
3. In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.

4. This filling machine equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.

5. It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.


Electrical component information
No Name Brand
1 Touch screen / HTM Siemens / Mitsubishi
2 PLC Siemens / Mitsubishi
3 Switch, Button Schneider
4 Air cylinder AIRTAC
5 Water pump CNP
6 Sensor / Approaching switch AUTONICS


Bottle Holder of Gallon Bottling machine:
