8040 Membrane 8TPH Reverse Osmosis Water Treatment Machine
Contact Person : Alice Gu
Phone Number : 86-13862320828
WhatsApp : +8615862615333
Minimum Order Quantity : | 1 set | Price : | USD$2350 |
---|---|---|---|
Packaging Details : | Wooden case | Delivery Time : | 15 days |
Payment Terms : | L/C, D/A, D/P, T/T, MoneyGram | Supply Ability : | 20 sets/month |
Place of Origin: | China | Brand Name: | FillPack |
---|---|---|---|
Certification: | CE, ISO9001 | Model Number: | RO-1000 |
Detail Information |
|||
Product Name: | Water Treatment System | Capacity: | 1000LPH |
---|---|---|---|
Warranty: | 1 Year Warranty | Type: | Reverse Osmosis |
RO Membrane's Desalting Rate: | 99% | Voltage: | 3PH 380V 50HZ |
Condition: | New | ||
High Light: | 1000lph reverse osmosis water treatment machine,ce reverse osmosis water treatment machine,1000lph reverse osmosis water purification machine |
Product Description
First stage pretreatment.(Sand filter)
The use of multi-medium quartz sand filters, main purpose is to remove the water contains sediment, manganese, rust, colloid material, mechanical impurities, suspended solids and other particles in the above 20UM of substances hazardous to health.
Second stage pretreatment (Carbon filter)
Activated carbon filters used to remove the pigment in the water, smell, a large number of chemical and biological organisms, reducing the residual value of water and pesticide pollution and other harmful pollutants.
Third stage pretreatment (Sodium ion exchanger)
Soldium ion exchanger uesd for water softening, primarily to remove hardness of water. So as to effectively prevent the reverse osmosis membrane fouling. System can automatically recoil,
Fourth stage pretreatment (Precision filter)
Particle size in water to remove fine particles, sand filters can remove very small colloidal particles in the water, so that the turbidity reached 1 degree.
RO system
The core equipment of water pump is imported and the membrane film is imported from Hydranautics in America. It is equipped with full set of clean unit. It has the features of simple structure, convenient operation and high technological level.
Raw water pump
|
provide the pressure to quartz sand filter/active carbon filter/ water softener
|
|||
Sand filter
|
Get rid of turbidity, suspended matter
|
|||
Active Carbon filter
|
Remove the color, free chloride, organic matter, harmful matter, ect.
|
|||
Softener
|
Exchange "ions" of calcium and magnesium with the most common and easiest method.
|
|||
Precision filter
|
Prevent large particles into RO membrane, accuracy is 5um
|
|||
High pressure pump
|
Provide the high pressure to RO membrane
|
|||
RO system
|
Main part of the plant. The RO membrane's desalting rate can reach 97% and above, removing over 99% ions.
|
