20 L Bottle Mineral Water SUS304 3 Gallon Filling Line

Minimum Order Quantity : 1 set Price : USD $6000-$8000/set
Packaging Details : wooden case Delivery Time : 15-20 working days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 20 sets/month
Place of Origin: ZhangJiaGang JiangSu China Brand Name: FILL PACK
Certification: CE, ISO9001 Model Number: QGF-450

Detail Information

Bottle Volume: 10-20 L Bottle Capacity: 450BPH
Control: PID Material: SUS304
Dimension(L*W*H): 3600*2000*1800mm Automatic Grade: Full Auto
Rotary External Washer: 1800*1550*1750 Checking Light: 1000*100*450
High Light:

SUS304 Gallon filling line

,

3 Gallon mineral water filling machine

,

450BPH 5 gallon filling machine

Product Description

Description of 450BPH Water 3 / 5 Gallon filling line with stainless steel material



The 20 liter mineral water bottle filling machine is composed of barrel washer, barrel filling machine and barrel sealer into one unit.
Especially for filling drinking water of 3 and 5 gallons. It is an idea filling line to produce mineral water, distilled water and purified water.



Equipment list of 5 Gallon filling line:

1.1 Automatic De-capper BG-1 600*600*2000 1set
1.2 Rotary external washer RXT-3 1800*1550*1750 1set
1.3 L type Washer/Filler/Capper with auto bottle loading WFC-450H 3600*2000*1800 1set
1.4 Heat Shrinking Machine / 800*600*1200 1set
1.5 Checking Light CL-1 1000*100*450 1pc
1.6 Conveyor Belt with Motor / 10m+2 motors 1set


The whole 5 Gallon filling line includes Automatic De-capper, Rotary external washer, L type Washer/Filler/Capper, Heat Shrinking Machine, Checking Light



1, Automatic De-capper:

This single-head de-capping machine is fully automatic. When the gallon drum enters the capping machine along with the transportation, the capping head will automatically pull the lid off the barrel.

Dimension: 600*600*2000mm
Weight: 80kg



2, Rotary external washer



3, Monoblock gallon rinser-filler-capper

The whole 5 Gallon filling line is using stainless steel 304 shell which is corrosion resistant and easy cleaning. Main electric parts are famous brand. Air channel system use Air TAC brand product.The machine is with compact construction, just occupy small room, working efficiency is very high.



4, Steam shrink Machine
5, Ink jet code printer

20 L Bottle Mineral Water SUS304 3 Gallon Filling Line 0

20 L Bottle Mineral Water SUS304 3 Gallon Filling Line 1
