Jar Water 450BPH 5 Gallon Bottle Filling Machine
Contact Person : Alice Gu
Phone Number : 86-13862320828
WhatsApp : +8615862615333
| Minimum Order Quantity : | 1 set | Price : | USD $6000-$8000/set |
|---|---|---|---|
| Packaging Details : | wooden case | Delivery Time : | 15-20 working days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 20 sets/month |
| Place of Origin: | ZhangJiaGang JiangSu China | Brand Name: | FILL PACK |
|---|---|---|---|
| Certification: | CE, ISO9001 | Model Number: | QGF-450 |
|
Detail Information |
|||
| Bottle Size: | 3~5 Gallon Bottle | Capacity: | 450BPH |
|---|---|---|---|
| Filling Material: | Water | Function: | Washing Filling Capping |
| Dimension(L*W*H): | 3600*2000*1800mm | Packaging Type: | Barrel, Bottles |
| Feature: | High Efficiency | Inkjet Code Printer: | 347*220*100 |
| High Light: | 450BPH 5 gallon bottle filling line,450BPH 3 Gallon Filling Line,SS304 Barrel Filling Line |
||
Product Description
Description of 450BPH 3 / 5 gallon bottle filling line for making pure water
Equipment list of 5 gallon bottle filling line:
| 1.1 | Automatic De-capper | BG-1 | 600*600*2000 | 1set |
| 1.2 | Rotary external washer | RXT-3 | 1800*1550*1750 | 1set |
| 1.3 | L type Washer/Filler/Capper with auto bottle loading | WFC-450H | 3600*2000*1800 | 1set |
| 1.4 | Heat Shrinking Machine | / | 800*600*1200 | 1set |
| 1.5 | Checking Light | CL-1 | 1000*100*450 | 1pc |
| 1.6 | Conveyor Belt with Motor | / | 10m+2 motors | 1set |
| 1.7 | Inkjet code printer | 0H-338 |
347*220*100 |
1set |
Application of 5 gallon bottle filling line:
It is especially used for 3/5 Gallon barrel pure water washing, filling, capping production line.
Characteristics of 5 gallon bottle filling line:
The parts with touch water adopt high-quality stainless steel. The cylinder gear runs smoothly and the fixed position is correct. It adopts inserting-type washing technology to remove washing blind angle.
Product Description of 5 gallon bottle filling line:
1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine
